Model

HB-7199-CA-A

Image sensor

High quality CMOS sensor

Effective pixels

2 megapixel

Video format

1920x1080/ 1600x896/ 1280x720/ 1024x576/ 960x720/ 960x540/ 912x512 / 864x480/ 800x600/ 800x448/ 640x480/ 640x360/ 624x352/ 480x272 / 432x240/ 424x240/ 384x216/ 368x208/ 320x240/ 320x180/ 272x144 / 160x120/ P30

Camera angle

88°(D)/80°(H)/ 50°(V)

Focal length

3.24mm

Minimum illumination

0.5Lux(F1.8, AGC ON)

Focus mode

Manual

Aperture

Fixed

Inverse light contrast

Open/close

Exposure

Exposure parameters adjustable, support for automatic exposure

Video regulation

Luminance, clarity, saturation, contrast ratio, white balance, transmission gain, Anti-flicker, low brightness compensation and other parameters can be adjusted

Siginal noise ratio

＞50dB

Video interface

USB 2.0

Video compression format

MJPEG、YUV2、H.264、H.265

Audio input

Built-in high sensitive pickup

Working voltage

5V

Working current

500mA

Power

2.5W

Dimension

102mm(L)×46mm(W)×30mm(H)

Weight

0.15 kg

Storage temperature

-10℃～+60℃

Storage humidity

20℃～95℃

Working temperature

-10℃～+50℃

Working humidity

20℃～80℃

Operating environment

Indoor
