Asus ProArt Ryzen AM4 ATX Content Creation Motherboard (X570)
We ship throughout Karachi, Lahore, Islamabad, Rawalpindi and all over the country.
Get your order to your doorstep within 24 hours through iShopping’s Express Delivery (on eligible items).
About this Item
Asus ATX Motherboard Delivered All Over Pakistan
iShopping.pk brings you the best price for Asus ProArt Ryzen AM4 ATX Content Creation Motherboard (X570) with express shipping all over Pakistan.
Specifications:
|
CPU |
|
|
Chipset |
AMD X570 |
|
CPU Socket |
AM4 |
|
Back Panel I/O |
|
|
USB |
4 x USB 3.1 / USB 3.2 Gen 1 Type-A |
|
4 x USB 3.1 / USB 3.2 Gen 2 Type-A |
|
|
Thunderbolt |
2 x Thunderbolt 4 |
|
Display |
1 x DisplayPort Input |
|
1 x HDMI |
|
|
Audio |
5 x 3.5 mm |
|
Ethernet / Controller |
1 x Intel I225-V 2.5Gigabit |
|
1 x Marvell AQtion AQC113CS 10GbE |
|
|
Wi-Fi Antenna |
2 x Connector |
|
Buttons |
BIOS Flashback |
|
Memory |
|
|
Memory Slots |
4 x 288-Pin |
|
Memory Support |
DDR4 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3400, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4600, 4800 MHz |
|
Maximum Capacity |
128 GB |
|
Channel Architecture |
Dual Channel |
|
ECC Support |
Non-ECC, ECC Unbuffered |
|
Storage Expansion |
|
|
SATA |
6 x SATA III |
|
M.2 |
2 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, SATA (Unspecified)) |
|
1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4) |
|
|
RAID Support |
RAID 0, 1, 10 (M.2) |
|
Internal I/O |
|
|
Expansion Slots |
2 x PCIe 4.0 x16 |
|
1 x PCIe 4.0 x16 (x4 mode) |
|
|
USB |
1 x USB 3.1 / USB 3.2 Gen 2 Header (Supports 1 USB Type-C Port) |
|
1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port) |
|
|
3 x USB 2.0 Header (Supports 6 USB Type-A Port) |
|
|
Air Cooling |
2 x 4-Pin CPU |
|
4 x 4-Pin System |
|
|
Liquid Cooling |
2 x 4-Pin Pump |
|
Power Connectors |
1 x 24-Pin Mainboard |
|
1 x 8-Pin ATX |
|
|
1 x 4-Pin ATX |
|
|
Security |
Chassis Intrusion, TPM Header |
|
LED Header |
4 x RGB |
|
Diagnostics |
Clear CMOS |
|
Add-On |
2 x Thunderbolt Card Header |
|
Legacy |
1 x Serial |
|
BIOS |
|
|
ROM |
256 Mb |
|
Front Panel I/O |
|
|
I/O Connection Headers |
AAFP, USB 3.1 / USB 3.2 Gen 1, USB 3.1 / USB 3.2 Gen 2 |
|
Audio |
|
|
Audio Codec |
Realtek S1220A (7.1-Channel) |
|
Wireless |
|
|
Bluetooth |
5.2 |
|
Wi-Fi |
Wi-Fi 6E (802.11ax) (MU-MIMO) |
|
Software |
|
|
Supported Operating Systems |
Windows 10 (64-Bit) |
|
Physical |
|
|
Form Factor |
ATX |
|
Dimensions |
9.6 x 12" / 24.4 x 30.5 cm |
Specification
