Asus Prime X570-PRO/CSM AMD AM4 ATX Gaming Motherboard
We ship throughout Karachi, Lahore, Islamabad, Rawalpindi and all over the country.
Get your order to your doorstep within 24 hours through iShopping’s Express Delivery (on eligible items).
About this Item
iShopping.pk brings you the best price for Asus Prime X570-PRO/CSM AMD AM4 ATX Gaming Motherboard with express shipping all over Pakistan.
Features:
AMD AM4 Socket: Ready for 3rd and 2nd Gen AMD Ryzen™ processors
ASUS Corporate Stable Model (CSM): A commercial program offers up to 36-month product lifecycle and 6-month EOL notice for product transitions
ASUS Control Center Express: A centralized server-grade management software for asset management, software deployment and monitoring and mobile control
Enhanced power solution: 12+2 DrMOS power stages, ProCool connectors, alloy chokes and durable capacitors for stable power delivery
5-Way Optimization: One-click, system-wide tuning delivers optimized overclocks and intelligent cooling for CPU or GPU-intensive tasks
Industry-leading cooling options: Comprehensive controls for fans and dual pump headers, via Fan Xpert 4 or the acclaimed UEFI
M.2 heatsink: Ultra-efficient heatsink reduces M.2 SSD temperature for unthrottled transfer speeds and enhanced reliability
Next-gen connectivity: Supreme flexibility with PCIe 4.0, dual M.2, USB 3.2 Gen 2 ports and front-panel header
Specifications:
|
CPU |
AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
|
Chipset |
AMD X570 |
|
Memory |
3rd Gen AMD Ryzen™ Processors |
|
4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/ 3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory |
|
|
2nd Gen AMD Ryzen™ Processors |
|
|
4 x DIMM, Max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/ 2400/2133 MHz Un-buffered Memory |
|
|
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
|
|
4 x DIMM, Max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Un-buffered Memory |
|
|
Dual Channel Memory Architecture |
|
|
ECC Memory (ECC mode) support varies by CPU. |
|
|
Graphic |
Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
|
Multi-VGA output support : HDMI/DisplayPort ports |
|
|
- Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz |
|
|
- Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz |
|
|
Multi-GPU Support |
3rd and 2nd Gen AMD Ryzen™ Processors |
|
Supports NVIDIA® 2-Way SLI® Technology |
|
|
Supports AMD 3-Way CrossFireX™ Technology |
|
|
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
|
|
Supports AMD 2-Way CrossFireX™ Technology |
|
|
Expansion Slots |
3rd Gen AMD Ryzen™ Processors |
|
2 x PCIe 4.0 x16 (x16 or dual x8) |
|
|
2nd Gen AMD Ryzen™ Processors |
|
|
2 x PCIe 3.0 x16 (x16 or dual x8) |
|
|
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
|
|
1 x PCIe 3.0 x16 (x8 mode) |
|
|
AMD X570 chipset |
|
|
1 x PCIe 4.0 x16 (max at x4 mode) |
|
|
3 x PCIe 4.0 x1 |
|
|
Storage |
3rd Gen AMD Ryzen™ Processors : |
|
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support |
|
|
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : |
|
|
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support |
|
|
AMD X570 chipset : |
|
|
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support |
|
|
6 x SATA 6Gb/s port(s) |
|
|
Support Raid 0, 1, 10 |
|
|
LAN |
Intel® I211-AT |
|
ASUS LAN Guard |
|
|
Audio |
Realtek® S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3 |
|
- Impedance sense for front and rear headphone outputs |
|
|
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers |
|
|
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking |
|
|
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) |
|
|
- Front panel audio connector (AAFP) |
|
|
- Supports up to 32-Bit/192kHz playback * |
|
|
Audio Feature : |
|
|
- Optical S/PDIF out port(s) at back panel |
|
|
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference |
|
|
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals |
|
|
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity |
|
|
- EMI protection cover to prevent electrical noise to affect the amplifier quality |
|
|
USB Ports |
3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : |
|
4 x USB 3.2 Gen 1 port(s) (4 at back panel, blue, Type-A) |
|
|
AMD X570 chipset : |
|
|
1 x USB 3.2 Gen 2 front panel connector port(s) |
|
|
AMD X570 chipset : |
|
|
4 x USB 3.2 Gen 2 port(s) (4 at back panel, teal blue, 3 x Type-A+1 x Type-C) |
|
|
AMD X570 chipset : |
|
|
2 x USB 3.2 Gen 1 port(s) (2 at mid-board) |
|
|
AMD X570 chipset : |
|
|
4 x USB 2.0 port(s) (4 at mid-board) |
|
|
Special Features |
5-Way Optimization by Dual Intelligent Processors 5 |
|
- 5-Way Optimization tuning key perfectly consolidates TPU Insight, EPU Guidance, DIGI+ VRM, Fan Expert 4, and Turbo App |
|
|
DIGI+ VRM: Digital power design with Dr. MOS |
|
|
EPU Guidance |
|
|
TPU Insight |
|
|
Fan Xpert4 |
|
|
- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control |
|
|
Turbo App: system performance tuning, network priority, and audio scene configuration for selected applications. |
|
|
ASUS 5X Protection III : |
|
|
- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage |
|
|
- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! |
|
|
- ASUS Overvoltage Protection: World-class circuit-protecting power design |
|
|
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! |
|
|
- ASUS DIGI+ VRM - Digital power design with Dr. MOS |
|
|
- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention |
|
|
- ASUS ESD Guards - Enhanced ESD protection |
|
|
ASUS SafeSlot - Protect your graphics card Investment |
|
|
ASUS OptiMem： |
|
|
- Improved DDR4 Stability |
|
|
AURA : |
|
|
- Aura Lighting Control |
|
|
- Aura RGB Strip Headers |
|
|
- Addressable Gen 2 Header |
|
|
ASUS Exclusive Features : |
|
|
- AI Suite 3 |
|
|
- Ai Charger |
|
|
- Turbo LAN |
|
|
- Armoury Crate |
|
|
- Pre-mounted I/O Shield |
|
|
ASUS Quiet Thermal Solution : |
|
|
- Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan, PCH and M.2 Heatsink |
|
|
- ASUS Fan Xpert 4 |
|
|
ASUS EZ DIY : |
|
|
- ASUS CrashFree BIOS 3 |
|
|
- ASUS EZ Flash 3 |
|
|
- ASUS UEFI BIOS EZ Mode |
|
|
ASUS Q-Design : |
|
|
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) |
|
|
- ASUS Q-Slot |
|
|
- ASUS Q-DIMM |
|
|
- ASUS Q-Connector |
|
|
Back I/O Ports |
1 x PS/2 keyboard/mouse combo port(s) |
|
1 x DisplayPort |
|
|
1 x HDMI |
|
|
1 x LAN (RJ45) port(s) |
|
|
1 x Optical S/PDIF out |
|
|
5 x Audio jack(s) |
|
|
4 x USB 3.2 Gen 1 (up to 5Gbps) ports Type-A |
|
|
3 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A) |
|
|
1 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-C) |
|
|
Internal I/O Ports |
2 x Aura RGB Strip Headers |
|
1 x Addressable Gen 2 header(s) |
|
|
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) |
|
|
2 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode) |
|
|
1 x SPI TPM header |
|
|
1 x COM port(s) connector(s) |
|
|
6 x SATA 6Gb/s connector(s) |
|
|
1 x CPU Fan connector(s) (1 x 4 -pin) |
|
|
1 x CPU OPT Fan connector(s) (1 x 4 -pin) |
|
|
3 x Chassis Fan connector(s) (3 x 4 -pin) |
|
|
1 x PCH_FAN (1 x 4 -pin) |
|
|
1 x AIO_PUMP connector (1 x 4 -pin) |
|
|
1 x 24-pin EATX Power connector(s) |
|
|
1 x 8-pin ATX 12V Power connector(s) |
|
|
1 x 4-pin ATX 12V Power connector(s) |
|
|
1 x Front panel audio connector(s) (AAFP) |
|
|
1 x System panel(s) |
|
|
1 x Power-on button(s) |
|
|
1 x Clear CMOS jumper(s) |
|
|
1 x Node Connector(s) |
|
|
1 x Water Pump header (4-pin) |
|
|
1 x T_Sensor Connector |
|
|
1 x USB 3.2 Gen 2 (up to 10Gbps) connector |
|
|
1 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports |
|
|
Accessories |
User's manual |
|
2 x SATA 6Gb/s cable(s) |
|
|
1 x M.2 Screw Package |
|
|
1 x Supporting DVD |
|
|
1 x Q-connector(s) (1 in 1) |
|
|
1 x Extension cable for Addressable LED |
|
|
BIOS |
256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information |
|
Operating System |
Windows® 10 64-bit |
|
Form Factor |
ATX Form Factor |
|
12.0 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
