ASUS H110M-K 6th/7th Generation ATX Gaming Motherboard
We ship throughout Karachi, Lahore, Islamabad, Rawalpindi and all over the country.
Get your order to your doorstep within 24 hours through iShopping’s Express Delivery (on eligible items).
About this Item
iShopping.pk brings you the best price for ASUS H110M-K 6th/7th Generation ATX Gaming Motherboard with 3 years official warranty and express shipping all over Pakistan.
Specification:
|
CPU |
Intel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
|
Supports Intel® 14 nm CPU |
|
|
Supports Intel® Turbo Boost Technology 2.0 |
|
|
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. |
|
|
* Refer to www.asus.com for CPU support list |
|
|
Chipset |
Intel® H110 |
|
Memory |
2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory * |
|
Dual Channel Memory Architecture |
|
|
Supports Intel® Extreme Memory Profile (XMP) |
|
|
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. |
|
|
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
|
|
* The maximum memory frequency supported varies by processor. |
|
|
* Due to Intel® chipset limitation, DDR4 2400MHz memory frequency is only supported by 7th Generation Intel® processors. Higher memory modules will run at the maximum transfer rate of DDR4 2400MHz. |
|
|
** Due to Intel® chipset limitation, DDR4 2133MHz and higher memory modules on 6th Generation Intel® processors will run at the maximum transfer rate of DDR4 2133MHz. |
|
|
Graphic |
Integrated Graphics Processor- Intel® HD Graphics support |
|
Multi-VGA output support : DVI-D/RGB ports |
|
|
- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz |
|
|
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz |
|
|
Maximum shared memory of 1024 MB |
|
|
Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ |
|
|
Expansion Slots |
1 x PCIe 3.0/2.0 x16 (x16 mode, gray) |
|
2 x PCIe 2.0 x1 |
|
|
Storage |
Intel® H110 chipset : |
|
4 x SATA 6Gb/s port(s), gray |
|
|
LAN |
Realtek® RTL8111H, 1 x Gigabit LAN Controller(s) |
|
Audio |
Realtek® ALC887 8-Channel High Definition Audio CODEC *1 |
|
- Supports : Jack-detection, Front Panel Jack-retasking |
|
|
Audio Feature : |
- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path. |
|
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference |
|
|
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals |
|
|
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity |
|
|
USB Ports |
Intel® H110 chipset : |
|
6 x USB 2.0/1.1 port(s) (4 at back panel, black, Type-A, 2 at mid-board) |
|
|
Intel® H110 chipset : |
|
|
4 x USB 3.1 Gen 1 port(s) (2 at back panel, blue, Type-A, 2 at mid-board) |
|
|
Special Features |
ASUS 5X Protection II : |
|
- ASUS LANGuard - 2.5X higher surge tolerance |
|
|
- ASUS Overvoltage Protection - World-class circuit-protecting power design |
|
|
- ASUS DIGI+ VRM - 5 Phase digital power design |
|
|
- ASUS DRAM Overcurrent Protection - Prevents damage from short circuits |
|
|
- ASUS Stainless-Steel Back I/O - 3X corrosion-resistance for greater durability |
|
|
ASUS EPU : |
|
|
- EPU |
|
|
ASUS Exclusive Features : |
|
|
- AI Suite 3 |
|
|
- Ai Charger |
|
|
- Anti-Surge |
|
|
- USB 3.0 Boost |
|
|
- Disk Unlocker |
|
|
- Mobo Connect |
|
|
- PC Cleaner |
|
|
ASUS Quiet Thermal Solution : |
|
|
- Stylish Fanless Design Heat-sink solution |
|
|
- ASUS Fan Xpert |
|
|
ASUS EZ DIY : |
|
|
- ASUS CrashFree BIOS 3 |
|
|
- ASUS EZ Flash 3 |
|
|
- ASUS UEFI BIOS EZ Mode |
|
|
- Push Notice |
|
|
ASUS Q-Design : |
|
|
- ASUS Q-Slot |
|
|
- ASUS Q-DIMM |
|
|
Media Streamer |
|
|
Operating System Support |
Windows® 10 , 64bit |
|
Windows® 8.1 , 64bit |
|
|
Windows® 7 , 32bit/64bit *2 |
|
|
Back I/O Ports |
1 x PS/2 keyboard (purple) |
|
1 x PS/2 mouse (green) |
|
|
1 x DVI-D |
|
|
1 x D-Sub |
|
|
1 x LAN (RJ45) port(s) |
|
|
2 x USB 3.1 Gen 1 (blue) Type-A |
|
|
4 x USB 2.0 |
|
|
3 x Audio jack(s) |
|
|
Internal I/O Ports |
1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) |
|
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) |
|
|
1 x COM port(s) connector(s) |
|
|
4 x SATA 6Gb/s connector(s) |
|
|
1 x CPU Fan connector(s) (1 x 4 -pin) |
|
|
1 x Chassis Fan connector(s) (1 x 4 -pin) |
|
|
1 x S/PDIF out header(s) |
|
|
1 x 24-pin EATX Power connector(s) |
|
|
1 x 4-pin ATX 12V Power connector(s) |
|
|
1 x Front panel audio connector(s) (AAFP) |
|
|
1 x System panel(s) |
|
|
1 x Clear CMOS jumper(s) |
|
|
1 x 14-1 pin TPM connector |
|
|
Accessories |
User's manual |
|
I/O Shield |
|
|
2 x SATA 6Gb/s cable(s) |
|
|
1 x Supporting DVD |
|
|
BIOS |
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information |
|
Manageability |
WfM 2.0, DMI 3.0, WOL by PME, PXE |
|
Form Factor |
mATX Form Factor |
|
8.9 inch x 7.2 inch ( 22.6 cm x 18.3 cm ) |
Great-value micro-ATX H110 with 5X Protection II for dependable stability, LED-illuminated audio shielding and DDR4 support.
• 5X Protection II – Advanced hardware safeguards for all-round protection
• DDR4 memory compatibility
• Epic gaming audio with LED-illuminated shielding
• Media-acclaimed UEFI BIOS with EZ Flash 3
Advanced Hardware Safeguards:
Industry-leading 5X Protection II employs the finest components, excellent circuit design, and exacting standards to guarantee quality and long-term durability of your motherboard with all-round protection. For you, that means exceptional protection and stability for your build — the result of decades of engineering experience from the world's leading motherboard brand.
LANGuard:
Pumped-up throughput. 2.5X higher surge tolerance:
ASUS LANGuard is hardware-level networking protection that employs signal-coupling technology and premium anti-EMI surface-mounted capacitors ensuring a more reliable connection and better throughput, plus electrostatically-guarded and surge-protected components for greater tolerance to static electricity and improved protection against surges.
OvervoltageProtection:
World-class circuit-protecting power design:
An exclusive circuit design with built-in voltage regulators to protect your chipset, connectivity ports, and audio codecs from damage caused by unexpected high-level voltages from unstable or inferior power supplies.
|
|
|
|
|
DRAM Overcurrent Protection |
DIGI+ VRM |
Stainless-Steel Back I/O |
|
Short-circuit damage prevention |
Precision control for stable power |
3X corrosion-resistance for greater durability |
|
Onboard resettable fuses prevent overcurrent and short-circuit damage. This extends beyond I/O ports to DRAM to safeguard the lifespan of both your system and connected devices. |
ASUS-exclusive DIGI+ VRM intelligently delivers power to the processor based on real-time demands, reducing energy waste and improving system stability. |
Corrosion-resistant stainless steel back I/O panels bonded with chromium oxide have a lifespan that's three times (3X) longer than ordinary panels. |
ESD Guards:
Electrostatic discharge (ESD) can happen suddenly, and its damaging effects are easily underestimated. ASUS ESD Guards are tested to very high standards, capable of up to +/- 10kV for air discharge and +/-6kV for contact discharge. We employ an active protective circuit design to guard your system against electrostatic interference and damage, providing greater component longevity.
| |
|||
|
LAN port
|
USB connectors
|
VGA connectors
|
Keyboard and mouse connectors
|
| ESD TVS diode protection on the LAN circuit. | TVS diodes for surface-mount and dual-inline packages. | Additional on-circuit ESD TVS diodes to protect D-Sub functionality. | Additional on-circuit ESD transient-voltage-suppression (TVS) diodes. |
DDR4 Support:
Make your memory go faster:
With DDR4, you'll accelerate memory frequencies up to an incredible to 2133MHz! And ASUS works with almost every DDR4 memory vendor, so you're assured the best compatibility.
Media-acclaimed UEFI BIOS:
The smoothest, slickest mouse-controlled graphical BIOS has been improved to make it even more appealing. Whether you're a PC novice or a seasoned overclocker, the EZ and Advanced Modes help you find your way, quickly and easily.
EZ Flash 3:
Update the latest BIOS via the internet, and from within the BIOS.
S.M.A.R.T:
Check up your storages devices' Self-Monitoring, Analysis, and Reporting Technology (S.M.A.R.T) logs to gauge reliability, and even determine if they're about to fail.
Q-Fan Control:
You can configure the fan's operating speed manually, or use the easy pre-configured fan profiles to select Standard, Silent, Turbo, or Full Speed modes!
My Favorites:
Quickly find tuning options and add preferred tools to the list.
Instant front-panel USB 3.0 Experience:
We've put USB 3.0 right where you need it — two super-speed ports on the front panel. Experience data-transfer speeds up to 10X faster than USB 2.0 with instant plug-and-play connectivity, so no more back-breaking contortions in the hunt for hard-to-reach rear ports!
Q-Slot:
Effortless PCI Express component removal:
The large winged clip is easy to reach and easy to operate. Just press the Q-Slot clip lightly, and graphics card just pop out. Installing or removing even the biggest graphics cards is no sweat!..
Q-DIMM:
Easy memory removal:
Even if you work with a smaller case, just push down on the one-sided clip and push or pull RAM modules in or out – couldn't be simpler!
Fan Xpert:
Dedicated CPU and case fan controls:
Exclusive Fan Xpert ensures every fan achieves the best balance of cooling performance and low noise — and with our 100 series boards and their hardware-level 4-pin/3-pin PWM/DC mode for case fans, a simple BIOS adjustment lets you run your case fan in PWM/DC. Fan Xpert even includes Auto-Tuning mode to scan and detect all fan characteristics for single-click customization!
AI Suite 3:
One-stop access to innovative ASUS features:
ASUS AI Suite 3 offers a brand-new user experience through a clearer and more attractive interface with support for larger monitors. It consolidates all exclusive ASUS features into one simple-to-use package, allowing you to supervise overclocking, energy consumption, fan speeds, voltages and more. This all-in-one app offers diverse and easy to use functionality, with no need to switch back and forth between different utilities.
Intel CPU and chipset features;
Intel® H110 Chipset:
Intel® chipset is a single-chipset design that supports 6th-generation Intel LGA1151 Core™ i7/Core i5/Core i3/Pentium®/Celeron® processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. It natively supports up to four USB 3.0 ports for up to ten times faster transfer than USB 2.0. Moreover, Intel® H110 chipset also supports iGPU functions, letting users enjoy the latest Intel integrated graphics performance.
Ready for 6th-generation Intel LGA1151 Core i7/Core i5/Core i3/Pentium/Celeron processors:
This motherboard supports 6th-generation Intel Core i7/i5/i3/Pentium/Celeron processors in the LGA1151 package, with graphics, memory and PCI Express controllers integrated to support onboard graphics output with dedicated chipsets, dual channel (2 DIMM) DDR4 memory and 16 PCI Express 3.0/2.0 lanes for great graphics performance.
